Asynchronous static random access memory(SRAM)is a common storage solution in embedded system and cache design.Unlike synchronous SRAM,which relies on external clock,asynchronous SRAM directly controls read and write operations through input signals without waiting for clock edge trigger.This"instant response"feature makes it perform well in low-latency,random access scenarios.


The core memory cell of asynchronous SRAM adopts the classic 6-transistor(6T)structure,which consists of two cross-coupled inverters and two access transistors.This design can stably maintain the data state(0 or 1)and does not need to be refreshed regularly like DRAM.However,the 6T structure occupies a large chip area,which leads to the higher unit capacity cost of asynchronous SRAM than DRAM.

Macroscopically,asynchronous SRAM memory cells are arranged in a two-dimensional matrix:the row address decoder is responsible for selecting a certain row(word line),and the column address decoder selects a specific bit line,thus locating the unique memory cell.Take the common 64×8 specification as an example,which contains 6-64 row decoders,64 memory cell arrays and input/output buffers.Read and write operations are coordinated by the control logic according to chip selection,write enable,output enable and other signals,and the whole process does not depend on external clock.




①No clock dependence:all operations of asynchronous SRAM are directly triggered by address changes and control signals,and the access delay is fixed and predictable,which is suitable for asynchronous systems with strict timing requirements.

②Low power consumption and high stability:Static structure means that dynamic current is consumed only at the moment of reading and writing,and the leakage is small during standby.Cross-coupled inverters provide good anti-noise ability.

③Fast access speed:The access time of typical asynchronous SRAM can reach 10ns or even less,and it is often used in CPU cache,industrial control buffer and network equipment.

④Simple control:Compared with synchronous SRAM,the interface logic of asynchronous SRAM is more direct,which reduces the complexity of controller design.


As a well-known electronic component supplier and storage solution technology partner in the industry.The core business of Yingshang Microelectronics Company covers the supply of products such as memory chips,semiconductor devices,single-chip computers,Bluetooth chips and microswitches.Relying on the experienced technical team,it provides customers with accurate product selection,circuit design and product development support.For more information about asynchronous SRAM products,please contact Yingshangwei.
